Table 26. System Information details (continued)
Option Description
System Manufacturer Contact Information Specifies the contact information of the system manufacturer.
System CPLD Version Specifies the current version of the system Complex Programmable
Logic Device (CPLD) firmware.
UEFI Compliance Version Specifies the UEFI compliance level of the system firmware.
Memory Settings
To view the Memory Settings screen, power on the system, press F2, and click System Setup Main Menu > System BIOS
> Memory Settings.
Table 27. Memory Settings details
Option Description
System Memory Size Specifies the size of the system memory.
System Memory Type Specifies the type of memory installed in the system.
System Memory Speed Specifies the speed of the system memory.
Video Memory Specifies the size video memory.
System Memory Testing Specifies whether the system memory tests are run during system boot.
The two options available are Enabled and Disabled. This option is set to
Disabled by default.
Memory Operating Mode Specifies the memory operating mode. The option is available and is set
to Optimizer Mode, by default. Options such as Fault Resilient Mode and
NUMA Fault Resilient Mode are available for support when the Advanced
RAS capability processor is installed on the system.
Current State of Memory Operating Mode Specifies the current state of the memory operating mode.
Fault Resilient Mode Memory Size (%) Select to define the percent of total memory size that must be used by
the fault resilient mode, when selected in the Memory Operating Mode.
When Fault Resilient Mode is not selected, this option is grayed out and
not used by Fault Resilient Mode.
Node Interleaving Enables or disables the Node interleaving option. Specifies if the Non-
Uniform Memory Architecture (NUMA) is supported. If this field is set
to Enabled, memory interleaving is supported if a symmetric memory
configuration is installed. If the field is set to Disabled, the system
supports NUMA (asymmetric) memory configurations. This option is set
to Enabled by default.
ADDDC Settings Enables or disables ADDDC Setting feature. When Adaptive Double DRAM
Device Correction (ADDDC) is enabled, failing DRAMs are dynamically
mapped out. When set to Enabled it can impact the system performance
under certain workloads. This feature is applicable for x4 DIMMs only. This
option is set to Enabled by default.
Memory training When option is set to Fast and memory configuration is not changed,
the system uses previously saved memory training parameters to train
the memory subsystems and system boot time is also reduced. If memory
configuration is changed, the system automatically enables Retrain at
Next boot to force one-time full memory training steps, and then go back
to Fast afterward.
When option is set to Retrain at Next boot, the system performs the
force one-time full memory training steps at next power on and boot time
is slowed on next boot.
