Dell Precision 3440 Small Form Factor - Installing the M.2 2280 Pcie Solid-State Drive

Steps
1. Remove the screw (M2x3) that secures the solid-state drive to the system board.
2. Slide and lift the solid-state drive off the system board.
Installing the M.2 2280 PCIe solid-state drive
Prerequisites
About this task
The following image indicates the location of the solid-state drive and provides a visual representation of the installation procedure.
Disassembly and reassembly
29
