Steps
1. Disconnect the fan cable from the connector on the system board.
2. Loosen the four captive screws that secure the heat sink to the system.
NOTE: Loosen the screws in a sequential order (1,2,3,4) as mentioned on the system board.
3. Lift the heat-sink from the system board.
Installing the heat-sink
Prerequisites
About this task
The following image indicates the location of the VR heat sink and provides a visual representation of the installation procedure.
Disassembly and reassembly
39
