Steps
1. Insert the coin cell battery with the "+" sign facing up and slide it into the battery socket at an angle.
2. Press the battery into the connector until it clicks into place.
Next steps
1. Install the front bezel.
2. Install the side cover.
3. Follow the procedure in after working inside your computer.
Processor
Removing the processor
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the heat-sink.
About this task
NOTE:
The processor might still be hot after the computer is shut down. Allow the processor to cool down before
removing it.
The following images indicate the location of the processor and provide a visual representation of the removal procedure.
42
Disassembly and reassembly
