Dell Precision R5500 User Manual

Click Start , then click the arrow in the lower-right corner of the Start menu
as shown below, and then click Shut Down.
• In Windows XP:
Click Start → Turn Off Computer → Turn Off. The computer turns off after the
operating system shutdown process is complete.
2. Ensure that the computer and all attached devices are turned off. If your computer
and attached devices did not automatically turn off when you shut down your
operating system, press and hold the power button for about 6 seconds to turn them
off.
After Working Inside Your Computer
After you complete any replacement procedure, ensure you connect any external
devices, cards, and cables before turning on your computer.
1. Replace the cover.
CAUTION: To connect a network cable, first plug the cable into the network
device and then plug it into the computer.
2. Connect any telephone or network cables to your computer.
3. Connect your computer and all attached devices to their electrical outlets.
4. Turn on your computer.
5. Verify that the computer works correctly by running the Dell Diagnostics.
10

Dell Precision R5500 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
Processor cache	12 MB
Processor cores	4
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3 800/1066
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	96 GB
Storage media	HDD
Card reader integrated	-
Total storage capacity	320 GB
On-board graphics card	No
Discrete graphics card model	NVIDIA® Quadro® 600
On-board graphics card model	Not available
Discrete graphics card memory	1 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black, Silver
Audio system	Analog Devices ADI1984A
Product type	Workstation
Motherboard chipset	Intel® 5520
Password protection type	BIOS
Sustainability certificates	RoHS
Certification	CEC, WEEE, GS Mark, Energy Law, Green PC
Processor code	SLBV4
Processor ARK ID	47925
Processor package size	42.5 X 45 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	40 bit

Weight and Dimensions

Depth	753.6 mm
Width	440.6 mm
Height	86.3 mm
Weight	- g
