Installing the SAS Backplane
Installing the SAS Backplane
1. Push the blue release tabs and insert the backplane in the slot along the hard-drive
assembly.
2. Connect the SAS cables.
3. Install the hard drive assembly.
4. Install the hard drive carrier.
5. Install the optical drive.
6. Install the cooling shroud.
7. Install the cover.
8. Install the front bezel.
9. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the SAS Backplane
24
