Dell Precision R5500 - Computer Cover; Removing the Cover

3
Cover
Removing the Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the front bezel.
3. Rotate the latch-release lock counter-clockwise to the unlocked position.
4. Lift the latch and slide the cover towards the back of the computer.
5. Hold the cover on both sides and lift it away from the computer.
