Remote Access Host Card
Removing the Remote Access Host Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the front bezel.
3. Remove the cover.
4. Remove the cooling shroud.
5. Remove the optical drive.
6. Remove the hard drive carrier.
7. Remove the hard-drive assembly.
8. Remove the SAS Backplane.
9. Remove the power supply.
10. Remove the control panel.
11. Remove the system fans.
12. Remove the removable fan bracket.
13. Remove the expansion card cages.
14. Remove the power distribution unit.
15. Remove the center riser board.
16. Remove the CMOS battery.
17. Remove the video card.
18. Remove the SAS controller card.
19. Press the release latch to unsecure the Remote Access Host Card.
