19. Carefully lift the SAS Controller Card up and away from the computer.
Related Links
Installing the SAS Controller Card
Installing the SAS Controller Card
1. Place and insert the SAS controller card on the computer.
2. Replace the release latch to secure the SAS controller card.
3. Install the video card.
4. Install the CMOS battery.
5. Install the center riser board.
6. Install the power distribution unit.
7. Install the card cages.
8. Install the fan bracket.
9. Install the system fans.
10. Install the control panel.
11. Install the power supply.
12. Install the SAS backplane.
