Dell Precision R5500 User Manual

NOTE: The color of your computer and certain components may appear differently
than shown in this document.
To avoid damaging your computer, perform the following steps before you begin working
inside the computer.
1. Ensure that your work surface is flat and clean to prevent the computer cover from
being scratched.
2. Turn off your computer (see Turning Off Your Computer).
CAUTION: To disconnect a network cable, first unplug the cable from your
computer and then unplug the cable from the network device.
3. Disconnect all network cables from the computer.
4. Disconnect your computer and all attached devices from their electrical outlets.
5. Press and hold the power button while the computer is unplugged to ground the
system board.
6. Remove the cover.
CAUTION: Before touching anything inside your computer, ground yourself by
touching an unpainted metal surface, such as the metal at the back of the
computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity, which could harm internal components.
Recommended Tools
The procedures in this document may require the following tools:
• Small flat-blade screwdriver
• Phillips screwdriver
• Small plastic scribe
• Flash BIOS update program media
Turning Off Your Computer
CAUTION: To avoid losing data, save and close all open files and exit all open
programs before you turn off your computer.
1. Shut down the operating system:
• In Windows 7:
Click Start , then click Shut Down.
• In Windows Vista:
9

Dell Precision R5500 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
Processor cache	12 MB
Processor cores	4
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3 800/1066
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	96 GB
Storage media	HDD
Card reader integrated	-
Total storage capacity	320 GB
On-board graphics card	No
Discrete graphics card model	NVIDIA® Quadro® 600
On-board graphics card model	Not available
Discrete graphics card memory	1 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black, Silver
Audio system	Analog Devices ADI1984A
Product type	Workstation
Motherboard chipset	Intel® 5520
Password protection type	BIOS
Sustainability certificates	RoHS
Certification	CEC, WEEE, GS Mark, Energy Law, Green PC
Processor code	SLBV4
Processor ARK ID	47925
Processor package size	42.5 X 45 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	40 bit

Weight and Dimensions

Depth	753.6 mm
Width	440.6 mm
Height	86.3 mm
Weight	- g
