Dell Precision R5500 - Installing the Front-Chassis Assembly

Related Links
Installing the Front Chassis Assembly
Installing the Front-Chassis Assembly
1. Slide the front-chassis assembly towards the back of the computer until it clicks
into place.
2. Install the remote access host card.
3. Install the SAS controller card.
4. Install the video card.
5. Install the CMOS battery.
6. Install the center riser board.
7. Install the power distribution unit.
8. Install the card cages.
9. Install the fan bracket.
10. Install the system fans.
11. Install the control panel.
12. Install the power supply.
13. Install the SAS backplane.
14. Install the hard drive assembly.
15. Install the hard drive carrier.
16. Install the optical drive.
17. Install the cooling shroud.
18. Install the cover.
19. Install the front bezel.
20. Follow the procedures in After Working Inside Your Computer.
