Installing the Removable Fan Bracket
Installing the Removable Fan Bracket
1. Place the fan bracket in the computer.
2. Press both release tabs downwards simultaneously to secure the bracket.
3. Install the system fans.
4. Install the control panel.
5. Install the power supply.
6. Install the SAS backplane.
7. Install the hard drive assembly.
8. Install the hard-drive carrier.
9. Install the optical drive.
10. Install the cooling shroud.
11. Install the cover.
12. Install the front bezel.
13. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the Removable Fan Bracket
