Fan Bracket
Removing the Removable Fan Bracket
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the front bezel.
3. Remove the cover.
4. Remove the cooling shroud.
5. Remove the optical drive.
6. Remove the hard drive carrier.
7. Remove the hard-drive assembly.
8. Remove the SAS Backplane.
9. Remove the power supply.
10. Remove the control panel.
11. Remove the system fans.
12. Pull both release tabs upwards simultaneously to release the bracket.
13. Gently lift the removable fan-bracket from the computer.
