Dell Precision R5500 - Control Panel; Removing the Control Panel

10
Control Panel
Removing the Control Panel
CAUTION: Two different Torx drivers are needed for the control panel
disassembly/reassembly, a T10 and T8.
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the front bezel.
3. Remove the cover.
4. Remove the cooling shroud.
5. Remove the optical drive.
6. Remove the hard drive carrier.
7. Remove the hard-drive assembly.
8. Remove the SAS Backplane.
9. Remove the power supply.
10. Locate and remove the torx screw securing the control panel.
11. Remove the control panel cables.
