Dell Precision R5500 User Manual

1
Working on Your Computer
Before Working Inside Your Computer
Use the following safety guidelines to help protect your computer from potential damage
and to help to ensure your personal safety. Unless otherwise noted, each procedure
included in this document assumes that the following conditions exist:
• You have read the safety information that shipped with your computer.
• A component can be replaced or--if purchased separately--installed by performing
the removal procedure in reverse order.
WARNING: Before working inside your computer, read the safety information that
shipped with your computer. For additional safety best practices information, see
the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface, such as a
connector on the back of the computer.
CAUTION: Handle components and cards with care. Do not touch the components
or contacts on a card. Hold a card by its edges or by its metal mounting bracket.
Hold a component such as a processor by its edges, not by its pins.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,
not on the cable itself. Some cables have connectors with locking tabs; if you are
disconnecting this type of cable, press in on the locking tabs before you
disconnect the cable. As you pull connectors apart, keep them evenly aligned to
avoid bending any connector pins. Also, before you connect a cable, ensure that
both connectors are correctly oriented and aligned.
8

Dell Precision R5500 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
Processor cache	12 MB
Processor cores	4
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3 800/1066
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	96 GB
Storage media	HDD
Card reader integrated	-
Total storage capacity	320 GB
On-board graphics card	No
Discrete graphics card model	NVIDIA® Quadro® 600
On-board graphics card model	Not available
Discrete graphics card memory	1 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black, Silver
Audio system	Analog Devices ADI1984A
Product type	Workstation
Motherboard chipset	Intel® 5520
Password protection type	BIOS
Sustainability certificates	RoHS
Certification	CEC, WEEE, GS Mark, Energy Law, Green PC
Processor code	SLBV4
Processor ARK ID	47925
Processor package size	42.5 X 45 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	40 bit

Weight and Dimensions

Depth	753.6 mm
Width	440.6 mm
Height	86.3 mm
Weight	- g
