Card Slots
Slot 2 PCI Express x16 electrical and
mechanical, full-height, full-length
Slot 3 N/A
Slot 4 PCI Express x16 electrical and
mechanical, full-height, full-length
Center Riser Option 1:
Slot 5 PCI 32b, 5V, full-height, full-length
Slot 6 PCI Express x16 electrical and
mechanical, full-height, full-length
Center Riser Option 2:
Slot 5 PCI Express x8/x16 electrical/mechanical,
full-height, full-length
Slot 6 PCI Express x16 electrical and
mechanical, full-height, full-length
Rear IO:
Slot 7 PCI Express x4/x8 electrical/mechanical,
half-height, half-length
Drives
Externally accessible:
slimline SATA optical bays one
2.5 inch drive bays five SATA drives with onboard Intel
controller or six SAS drives with SAS/
PERC 6iR cards
Internally accessible none
External connectors
Audio stereo out, Mic/Line In
Network two RJ-45
Serial one 9-pin connector, 16550C-compatible
USB front panel: 2; rear panel: 4
Video video card dependant
99
