AH500 Programming Manual
6-290
All becomes 0.
The positions in whcih
t
he data is stored.
b3 b0
b7 b4
b11 b8
b15 b12
b3 b0
b15 b4
4
D0
1 2
3
4
D10
D11
D12
D13
1
2
3
4
Additional remark:
1. If D~D+(n-1) exceed the device range, the instruction is not executed, SM0 is ON, and the
error code in SR0 is 16#2003.
2. If n is less than 1, or if n is larger than 4, the instruction is not executed, SM0 is ON, and the
error code in SR0 is 16#200B.
