DEMAG DC-Com 5 User Manual

Curve radii in mm
Trolley size
SWL Runway girder Travel wheel
material
Push travel Electric travel
Flange width
23)
Rmin
Flange width
23)
Rmin
[kg] [mm] [mm] [mm] [mm]
CF 5 550 50-91 800 - - Plastic
U 11 DC EU 11 DC 1100 58-310 1000 58-310 2000
Plastic
24)
U 22 DC EU 22 DC 2200 82-200
2000
82-200
3000
Spheroidal
graphite cast iron
U 34 DC EU 34 DC
2200 201-310 201-310
Spheroidal
graphite cast iron
3400 82-310 82-310
RU 56 DC EU 56 DC 5600 98-310
2000
25)
98-310
2500
25)
Tab. 25
SWL
Chain hoist Reeving Possible cross-travel speeds in approx. ... m/min
V14/3 V12/4 V24/6 V40/10
[kg]
DC-Com Trolley Travel
drive
Trolley Travel
drive
Trolley Travel
drive
Trolley Travel
drive
80
to
500
1 to 5
1/1
- -
- - U 11 DC E 11 DC - -
200
to
1000
10
26)
EU 56 DC
ZBF 80 A
12/4
U 11 DC
EU 56 DC
E 11 DC
ZBF 71 A
8/2
EU 56 DC
ZBF 80 A
8/2
1250
2/1 U 22 DC
EU 56 DC
E 22 DC
ZBF 71 A
8/2
1/1
1600
2/1
2000
2500 U 34 DC E 34 DC EU 56 DC
ZBF 71 A
8/2
Tab. 26
For further possible applications see Technical data Demag DC-Com chain hoist .
● If the EU 56 DC travel drive is used with small flange widths it is necessary to fit supporting rollers to the trolleys.
● If several trolleys are operated on one girder, we recommend the use of trolley buffers to dampen any collisions
between the trolleys.
23)
Max. flange width 500 mm (except CF 5)
24)
Steel travel rollers optional
25)
From flange width 106 mm
26)
If DC-Com 10 is combined with EU 56 DC, a special crossbar is required.
21480244/181209
37
