Basic Operation Basic Operation
(Pro LogicII Cinema mode)
(Pro LogicII Music mode)
(Pro LogicII Game mode)
5
Press the CURSOR
DD
or
HH
button to select the
various surround parameters.
Example: DOLBY PLIIx Music mode screen
When set with the on screen display using the remote
control unit while in the MUSIC mode, set the “ ” mark
to “OPTIONS 0” pressing the CURSOR
DD
or
HH
button, then
press the CURSOR
FF
button.
Press the ENTER button to return to the previous screen.
When the “SB CH OUT” parameter is set to “OFF”. (Set
“Sp.Back” at the System Setup to “None”).
Display
MODE: PL C
*Surr Parameter
MODE: PL M
*Surr Parameter
MODE: PL G
*Surr Parameter
*Surr Parameter
MODE: DOLBY PL
(Dolby Pro Logic mode)
2 Surround parameters w
Pro LogicIIx and Pro LogicII Mode:
Select one of the modes (“Cinema”, “Music”, “Pro Logic” or
“Game”).
The Cinema mode is for use with stereo television shows and
all programs encoded in Dolby Surround.
The Music mode is recommended for stereo music and
surround-encoded stereo music sources.
The Pro Logic mode emulates Dolby Laboratories’ original
Dolby Pro Logic surround decoding, and may provide better
results with older, legacy surround-encoded program material.
The Game mode is optimized for computer and/or dedicated
game box consoles, that feature stereo analog or digital
outputs. It can only be used with 2-channel stereo sources.
PANORAMA:
This mode extends the front stereo image to include the
surround speakers for an exciting “wraparound” effect with
side wall imaging.
Select “OFF” or “ON”.
DIMENSION:
This control gradually adjust the soundfield either towards the
front or towards the rear.
The control can be set in 7 steps from 0 to 6.
CENTER WIDTH:
This control adjust the center image so it may be heard only
from the center speaker; only from the left/right speakers as a
phantom image; or from all three front speakers to varying
degrees.
The control can be set in 8 steps from 0 to 7.
• There are four Dolby Surround Pro Logic modes (NORMAL,
PHANTOM, WIDE and 3 STEREO). The AVR-4306 sets the
mode automatically according to the types of speakers set
during the system setup process ( page 82).
7
Press the ENTER or SURROUND PARAMETER
button to complete the setting.
6
Press the CURSOR
FF
or
GG
button to adjust the
parameters setting.
Press the CURSOR
FF
button to select “Default
Yes
00
”, then parameters set to default setting.
DEFAULT setting:
4
Press the CURSOR
FF
or
GG
button to select the
play mode.
Display
MODE: PL x C
*Surr Parameter
MODE: PL x M
*Surr Parameter
MODE: PL x G
*Surr Parameter
(Pro LogicIIx Cinema mode)
(Pro Logic
IIx Music mode)
(Pro LogicIIx Game mode)
When the “SB CH OUT” parameter is set to “ON”. (Set
“Sp.Back” at the System Setup to “1spkr” or “2spkrs”).

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
