3.1 Identification labels
Identification labelsIdentification labels
Identification labels
ROTOGRAPH PLUS is labeled with a set of labels identifying different
components according to the requirements of the international
standards.
The following picture shows the position of the different labels:
1
2
3
4
6
5
