SERVICE MANUAL
Checkout and adjustments
(Rev. 0) RTG PLUS (120V)
7-1
7.
7.7.
7.
CHECKOUT AND ADJUSTM
CHECKOUT AND ADJUSTMCHECKOUT AND ADJUSTM
CHECKOUT AND ADJUSTMENTS
ENTSENTS
ENTS
WARNING:
ALL THE FUNCTIONS OF THIS EQUIPMENT ARE PRE-CALIBRATED
AND CHECKED DURING THE FINAL TESTING IN THE FACTORY. ANY
CHANGES TO THE DEFAULT SETTING MAY ONLY BE CARRIED OUT
BY A DENT-X TECHNICIAN OR BY EXPRESSELY AUTHORISED
THIRD PARTIES. ANY CHANGES MADE BY UNAUTHORISED PEOPLE
WILL VOID ANY MANUFACTURER'S RESPONSIBILITY AS TO THE
CORRECT OPERATION AND SAFETY OF THIS EQUIPMENT.
NOTE:
The procedures explained in the next pages make often reference to
Figure 7-12, Figure 7-13 and Figure 7-14 at the end of this chapter. To
easily consult this Figures, unfold pages in order to make it visible while
reading other pages of the manual.
7.1
7.17.1
7.1
P
PP
Power up
ower upower up
ower up
When turning on the machine, before pressing any key on the remote
control wait for the CPU and remote control initial self-test to end, until
the remote control sets itself to PAN (27), Adult (33), Medium size (36).
If you press any key (except "s" (39), "increase" (41) and "decrease" (40))
during the self-test phase, such procedure will not be passed. The
machine will wait for the key to be released and then will start its normal
operation cycle.
Press "increase" (41) and "decrease" (40) during the self-test phase to
increase or decrease the brightness of the display.
To access the set-up phase, press "s" (39) during the self-test procedure.
*
