DENT-X ROTOGRAPH PLUS - TMJ1 and TMJ2 - ADULT and CHILD

SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-32
7.7.3
7.7.37.7.3
7.7.3 TMJ1 and TMJ2
TMJ1 and TMJ2 TMJ1 and TMJ2
TMJ1 and TMJ2 -
--
- ADULT and CHILD
ADULT and CHILD ADULT and CHILD
ADULT and CHILD
WARNING:
IN THIS FUNCTION, THE WIDTH OF THE BANDS MUST
CORRESPOND TO THE SIZES INDICATED IN FIGURE 7-9 AND
FIGURE 7-10, THAT IS 61mm FOR ADULTS AND 51mm FOR
CHILDREN.
IN THE EVENT THAT THE CONDYLE SHOULD NOT BE AT THE
CENTER OF THE 51/61mm BAND DURING THE TMJ2 PHASE
(EXPOSURE WITH OPEN MOUTH), THE PROBLEM IS BE DUE TO A
BAD POSITION OF THE PATIENT, NOT TO THE SIZE OF THE BANDS.
TMJ1
TMJ1TMJ1
TMJ1
1. Select the TMJ1 function (29) and adult (33) or child (34) size on the
remote control.
2. Press "T" (31) and release it immediately to display "T 020" (heating
time, cannot be changed) corresponding to 2 seconds.
3. Press "s" (39) to display the string "A1 ......." (X-ray emission start
angle, 1st exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final Test Table” (see the last
page of the User’s Manual).
4. Press "s" (39) to display the string "A2 ......." (X-ray emission end
angle, 1st exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final Test table”.
5. Press "s" (39) to display the string "A5 ......." (X-ray emission start
angle, 4th exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final Test Table”.
6. Press "s" (39) to display the string "A6 ......." (X-ray emission end
angle, 4th exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final test table”.
