DENT-X ROTOGRAPH PLUS - 7.5 Checking and centering adjustment of the X-ray beam

SERVICE MANUAL
Checkout and adjustments
(Rev. 0) RTG PLUS (120V)
7-15
7.5
7.57.5
7.5 Checking and centering adjustment of the X
Checking and centering adjustment of the XChecking and centering adjustment of the X
Checking and centering adjustment of the X-
--
-ray
ray ray
ray
beam
beambeam
beam
ROTOGRAPH PLUS does not usually require adjustment of the X-ray
beam. However, if necessary, follow the instructions provided in the next
paragraph to adjust the X-ray beam.
WARNING:
The followings test implies X-ray emission; please follow all
measures envisaged by local safety regulations.
NOTE:
At the end of the check and adjustment, record the serial number of
each diaphragms checked with the system onto the “Final Test
Table” (see the last page of the User’s Manual).
*
