DENT-X ROTOGRAPH PLUS - Out of Order N°1! Call Technical Assistance

SERVICE MANUAL
Checkout and adjustments
(Rev. 0) RTG PLUS (120V)
7-43
7.8.5
7.8.57.8.5
7.8.5 Ou
OuOu
Out of Order N°1! Call Technical Assistance
t of Order N°1! Call Technical Assistancet of Order N°1! Call Technical Assistance
t of Order N°1! Call Technical Assistance
This message can be displayed on two different conditions, due to a fault
of the potentiometer used to control angular position of the rotating arm.
This message can be caused by a failure of the potentiometer or a bad
contact in the harness between the potentiometer and the control circuit
(see chapter 9 – General diagram code 39099300 or 39099303 –
Page 4 of 5).
Another possible cause is the failure of one of the start/stop rotation
microswitch S2/S3 (see Figure 7-4 page 7-20). Check the microswitch
and/or harness.
