SERVICE MANUAL
Introduction
(Rev. 0) RTG PLUS (120V)
1-1
1.
1.1.
1.
INTRODUCTION
INTRODUCTIONINTRODUCTION
INTRODUCTION
NOTE:
The present manual is updated for the product it is sold with in order to
grant an adequate reference in performing diagnostics and repair
operations normally carried out by the service engineer.
The manual may not reflect changes to the product not impacting service
operations.
ROTOGRAPH PLUS, by DENT-X, is a radiological device which allows to
carry out radiological examinations of the dento maxillo facial complex.
ROTOGRAPH PLUS is available in the following version:
• For PANORAMIC examination only (ST version)
• For PANORAMIC examination and examination of the Temporo-
Mandibular Joint (TMJ)
• The latter is also available with the CEPHALOMETRIC device in order
to carry out CEPHALOMETRIC (CEPH) examination.
This manual provides to the operator the instructions for proper and safe
use of the appliance.
The appliance must be used strictly following the procedures described
in this manual and never for activities other than those for which it was
designed.
Before using the appliance, we recommend to read carefully this manual.
Keep it in a safe place near the unit for future reference.
ROTOGRAPH PLUS is an electromedical appliance and may be used only
under medical supervision, i.e. with the supervision of highly qualified
persons with the necessary know-how regarding X-ray protection.
The user is responsible for complying with the legal requirements
regarding the installation and operation of the equipment.
1.1
1.11.1
1.1
Icons appearing in the manual
Icons appearing in the manualIcons appearing in the manual
Icons appearing in the manual
Indicates a “NOTE”; the utmost attention shall be devoted to the
reading of paragraphs marked by this icon.
Indicates a “WARNING”; paragraphs marked with this icon cover
patient and/or operator safety aspects.
*
*
