DENT-X ROTOGRAPH PLUS - 7.2 Set-up

SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-2
7.2
7.27.2
7.2 Set
SetSet
Set-
--
-up
upup
up
This chapter explains how to enter same special routines (set-up mode)
that allow to carry out adjustment / settings on the unit.
7.2.1
7.2.17.2.1
7.2.1 Activation of the set
Activation of the setActivation of the set
Activation of the set-
--
-up programs
up programsup programs
up programs
Activation of the set-up mode is achieved as follow:
1. While holding the “s” button depressed, turn the machine ON and
do not let go until the unit has gone through its check out mode
which will be signaled by two distinct sound, one short and one long;
thereafter, the display would be blank.
2. Press keys 37, 34, 29 in sequence (small, child, TMJ1 buttons; see
Figure 7-13). The display will remain still blank.
3. The system is now waiting for one of the following selections:
• press "s" (39) to change the value of the "software DIP-switches"
• press "R" (32) to restore the default values of the operating
parameters in the Non-volatile RAM (NVRAM) memory
• press "T" (31) to calibrate the potentiometer used for the
detection of the position of the rotating arm.
WARNING:
Pressing "R" will cause the loss of all factory and/or custom adjusted
parameters.
