SERVICE MANUAL
Checkout and adjustments
(Rev. 0) RTG PLUS (120V)
7-3
7.2.2
7.2.27.2.2
7.2.2
Modification of the values of the "Software DIP
Modification of the values of the "Software DIPModification of the values of the "Software DIP
Modification of the values of the "Software DIP-
--
-Switches"
Switches"Switches"
Switches"
To select the status of each of the “software DIP-Switches (S0 to SB),
press the “s” key (39; see Figure 7-13).
To move to the next “software DIP-Switches”, press the “T” (31) key as
many time as required to read the desired functions.
The available “software DIP-Switches” are the following:
S0:
S0:S0:
S0:
Display number of performed exposures
Display number of performed exposuresDisplay number of performed exposures
Display number of performed exposures
When the display indicates "S0 OFF", press "s" (39) to change this
function to ON (S0 ON).
Now press "R" (32). By pressing the Pan (37), TMJ1 (29), TMJ2 (30)
and CEPH (28) function keys, the system will display the number of
the respective exposures performed. Do not press "R" (32) again.
To exit this set-up function (S0) and return to the normal working
function, press "s" (39). S0 will return automatically to OFF (S0
OFF).
To proceed with the set-up functions, repeat the actions described
at paragraph 7.2.
S1:
S1:S1:
S1:
Select display message language
Select display message languageSelect display message language
Select display message language
When the display indicates "S1 set language", press "s" (39) to
change the language of the display (ITA, ENG, FRA, DEU or ESP).
Once the desired language is selected, you can either go to the next
functions by pressing "T" (31) or return to the normal working
conditions by pressing "R" (32).
S2:
S2:S2:
S2:
Delay bet
Delay betDelay bet
Delay between two exposure, to allow tubehead anode
ween two exposure, to allow tubehead anode ween two exposure, to allow tubehead anode
ween two exposure, to allow tubehead anode
cooling
coolingcooling
cooling
If S2 is ON, there will be a cooling pause after each exposure. If S2
is OFF, several exposures can be performed without any delay,
which may affect the reliability of the tubehead life.
Once the desired setting is selected by pressing "s" (39), you can
either go to the next functions by pressing "T" (31) or return to the
normal working conditions by pressing "R" (32).
NOTE:
It is recommended to leave this function always ON (S2 ON).
*
