SERVICE MANUAL
Safety information
RTG PLUS (120V) (Rev. 0)
2-4
2.3
2.32.3
2.3
Symbols used
Symbols usedSymbols used
Symbols used
Symbol Description
Equipment with Type B applied parts (according to
IEC 601-1)
A number of machine parts contain materials and
liquids that upon completion of the machine’s life
cycle must be disposed of at recovery centers
established by the local health units
∼
∼∼
∼
Alternating Current
N Connection to neutral conductor
L Connection to line conductor
Protection ground
Functional ground
OFF ; equipment not connected to power line
ON ; equipment connected to power line
Warning: read the documentation provided with the
unit
