SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-28
7.7.1
7.7.17.7.1
7.7.1
PAN
PANPAN
PAN-
--
-ADULT
ADULTADULT
ADULT
1. Select the Pan function (27) and Adult size (33) on the remote
control.
2. Press "T" (31) and release it immediately to display "T 020" (heating
time, cannot be changed).
3. Press "s" (39). The string "A1 000" will be displayed (not used and
not modifiable).
4. Press "s" (39) to display the string "A2 ......." (X-ray emission start
angle), followed by a variable value which can be adjusted from 3°
(003.0) to 6° (006.00).
This procedure allows to "increase" or "decrease" the width of the
white (not exposed) band on the left side of the pan exposure shot
(see Figure 7-8). Such variation must be carried out by means of the
"increase" (41) or "decrease" (40) keys.
NOTE:
Before switching from one adjustment to the next, you will have to
confirm the new setting by pressing the "T" key (31).
5. Press "s" (39) to display the string "A3 ......." (motor deceleration
ramp end angle in the central area). This setting determines the
starting point of the rotation speed change (slowdown) which can be
modified by a max of ± 3° with respect to the value indicated in the
“Final Test Table” (see the last page of the User’s Manual).
Reducing the value will anticipate the rotation’s slow down area; this
will increase the area where the spine compensation will take effect.
6. Press "s" (39) to display the string "A4 ......." (motor acceleration
ramp end angle in the central area). This setting determines the
starting point of the rotation speed change (ramp up) which can be
modified of max ± 3° with respect to the value indicated in the “Final
Test table”.
*
