7.7 Changing angles and times
Changing angles and timesChanging angles and times
Changing angles and times
The S5 function allows to change the default angles and times for any
function and size. In particular, you can change the X-ray emission start
(A2) or end (A5) angles, the deceleration (A3) or acceleration (A4) ramp
start angles or the duration of the four TMJ exposures by simply using
the procedure here after described for the parameters you want to
change.
For all the following procedures hereafter described, entering the set-up
program is required (see paragraph 7.2), then press “s” (39) followed by
“T” (31) several times until the function “S5 ......” is displayed and press
“s” key to set “S5 ON” (see paragraph 7.2.2, function "S5" for further
details).
NOTE:
Press "R" (32) to exit the S5 function. This will not set automatically
function S5 to OFF (S5 OFF) and after an exposure the string "T1 020"
will be displayed.
To access the normal working function again, return to the set-up
program and change S5 to OFF.
NOTE:
Every change must be carried out by pressing the "increase" (41) and
"decrease" (40) keys.
*
*
