SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-26
• T
TT
TMJ2 function (30), Adult
MJ2 function (30), AdultMJ2 function (30), Adult
MJ2 function (30), Adult-
--
-Child (33 or 34)
Child (33 or 34)Child (33 or 34)
Child (33 or 34)
T1: Heating time of filament (cannot be changed)
A1: X-ray emission start angle II° exposure (can be changed)
A2: X-ray emission end angle II° exposure (can be changed)
A3: K20 relay closing angle (can be changed, but is insignificant)
A4: K20 relay opening angle (can be changed, but is insignificant)
A5: X-ray emission start angle III° exposure (can be changed)
A6: X-ray emission end angle III° exposure (can be changed)
T2: Arm rotation time (cannot be changed)
T3: Actual X-ray emission time (II°+III° exp.) (cannot be changed)
