DENT-X ROTOGRAPH PLUS - Page 120

SERVICE MANUAL
Spare Parts
RTG PLUS (120V) (Rev. 0)
10-2
1
1 1
1 -
--
- STAND
STAND STAND
STAND
Ref.
Ref.Ref.
Ref. Order code
Order codeOrder code
Order code Description
DescriptionDescription
Description
ETL std
ETL std ETL std
ETL std
version
versionversion
version
ETL “ST”
ETL “ST” ETL “ST”
ETL “ST”
version
versionversion
version
1 7108423005 Unblock rotation tubehead X
2 5108400600 Safety plate for Tubehead block X X
5608433505 Tubehead arm cover X 3
5608433605 Tubehead arm cover ST version X
4 5608661005 Upper Tubehead cover X X
5 5608661103 Lower Tubehead cover X X
6608661403 Collimator cover X 6
6608661203 Collimator cover ST version X
7 7208432300 Rotation tubehead microswitch X
6208610600 Tubehead cable X 8
6208610500 Tubehead cable X
6608660103 Tubehead Assy without collimator X 9
6608660003 Tubehead Assy without collimator for
“ST” version
X
10 7208131800 X1 + X7 with tube housing X X
11 7108122005 Counterweight pulley Assy X X
12 5008120100 Counterweight rope X X
13 6608106000 Counterweight chain and ropes Assy X X
6608651500 Collimator Assy X 14
6108662000 Collimator Assy ST version X
15 5508100600 Fe counterweight X X
16 5508102400 Pb counterweight X
17 4208403700 Microswitch X
6208433000 Tubehead harness X 18
6208432800 Tubehead harness X
19 6208526700 Tubehead internal cable X X
-- 8108126005 Wall mounting kit (without legs) X X
-- 8108127003 Floor mounting kit (with legs) X X
