DENT-X ROTOGRAPH PLUS - Page 122

SERVICE MANUAL
Spare Parts
RTG PLUS (120V) (Rev. 0)
10-4
Ref.
Ref.Ref.
Ref. Order code
Order codeOrder code
Order code Description
DescriptionDescription
Description
ETL std
ETL std ETL std
ETL std
version
versionversion
version
ET
ETET
ETL “ST”
L “ST” L “ST”
L “ST”
version
versionversion
version
1 6108317000 Connecting rod Assy X X
2 7108322000 Rotation arm unclamp X X
3 6608318900 Motor with gear box Assy X X
4 4192004000 Potentiometer for angular check (10K) X X
5 5971313900 Small gear for potentiometer X X
6 5908323100 Big gear for potentiometer X X
7 6608317700 Eccentric Ball bearing Assy X X
8 6608310600 Central ball bearing Assy X X
9 4908315900 Toothed belt X X
10 6608314800 Chain Assy X X
11 6108312700 Tightener Assy X X
12 6608314900 Eccentric Ball bearing Assy X X
13 5608433405 Lower rotating arm cover X X
14 7108520003 Temples clamp X X
15 5708801600 Temples clamp friction spring X X
