DENT-X ROTOGRAPH PLUS - Page 124

SERVICE MANUAL
Spare Parts
RTG PLUS (120V) (Rev. 0)
10-6
Ref.
Ref.Ref.
Ref. Order code
Order codeOrder code
Order code Description
DescriptionDescription
Description
ETL std
ETL std ETL std
ETL std
version
versionversion
version
ETL “ST”
ETL “ST” ETL “ST”
ETL “ST”
version
versionversion
version
1 5408926500 Rotograph PLUS label X X
2 6608203500 Centering mirror X X
3 6208404100 Cassette Microswitch Assy X X
4 5808527600 Chin support PCB X X
5 6208526900 Brake pushbutton X X
6 6208525700 Pushbutton centering X X
7 6108201900 Centering movement knob X X
8 6608223000 Brake Assy X X
9 5608121605 Rear column cover X X
10 5608433705 TMJ device cover X
11 6208432500 Rotation arm stop microswitch Assy X
12 6608433000 TMJ device X
13 7108431500 Tightner gear Assy X X
14 7208404500 Stop-Starter microswitch X X
15 5608402605 Upper rotating arm cover X X
16 6608317600 Chain Assy X X
17 4508212900 Centering lamp X X
18 6208527700 Interlocks cable X X
