SERVICE MANUAL
Spare Parts
RTG PLUS (120V) (Rev. 0)
10-8
2
2 2
2 –
––
– CONTROL BOX
CONTROL BOX CONTROL BOX
CONTROL BOX
Ref.
Ref.Ref.
Ref.
Order code
Order codeOrder code
Order code
Description
DescriptionDescription
Description
ETL std
ETL std ETL std
ETL std
version
versionversion
version
ETL “ST”
ETL “ST” ETL “ST”
ETL “ST”
version
versionversion
version
1 7208755503 Hand held control (without cable) X X
2 6208746600 Hand held control cable X X
3 5808756200 EPROM for remote control X X
4 8308753003 Control box complete X X
5 5608125405 Control box cover X X
6 4291415900 Bipolar switch S9 X X
7 6608754300 Power board PCB A1 X X
8 8008600476 PCB A1–F1 fuse 2AT (5 x 20) X X
9 8008610107 PCB A1-F2 fuse 3AT (5 x 20) X X
10 8008610137 PCB-A1-F3 fuse 8AF (6.3 x 32) X X
11 2300978300 PCB-A1–F4 fuse 315mAF (5 x 20) X X
12 5808755000 CPU PCB A2 X X
13 5808755200 EPROM for CPU board X X
14 8008600493 CPU A2 Board – Fuse F1 1AT (5 x 20) X X
15 8008610014 CPU A2 Board – Fuse F2 500mA (5 x 20) X X
16 8008600493 CPU A2 Board – Fuse F3 1AT (5 x 20) X X
17 4492819700 Mono-phase autotransformer T1 (120V) X X
18 4492819800 Transformer T2 (120V) X X
19 4192207500 Line filter X X
20 2300977000 Line fuse F1 10AT (6.3 x 32) X X
21 2300975100 Line fuse F2 1AT (6.3 x 32) X X
22 6208746400 Flat cable X16 X X
23 6208741400 Flat cable X17 X X
