DENT-X ROTOGRAPH PLUS - Page 128

SERVICE MANUAL
Spare Parts
RTG PLUS (120V) (Rev. 0)
10-10
3
3 3
3 –
––
– CEPH DEVICE
CEPH DEVICE CEPH DEVICE
CEPH DEVICE
Ref.
Ref.Ref.
Ref. Order code
Order codeOrder code
Order code Description
DescriptionDescription
Description
ETL std
ETL std ETL std
ETL std
version
versionversion
version
ETL “ST”
ETL “ST” ETL “ST”
ETL “ST”
version
versionversion
version
1 6609802900 Rod for CEPH centering device X
2 6608822500 Rod and SFD centering device X
3 6608906100 Ceph ear pivot (10 pcs) X
4 5909803800 Nose-rest rod X
5 4291307700 CEPH cassette microswitch X
6 6609803500 Nose-rest rod assy X
7 5408823605 Skull clamp cover X
8 6208813100 Stop CEPH arm pushbutton X
9 4890307900 Knob X
10 2100441000 Plug 6.5 DP-250 2604 BI HEYCO (1 pcs) X
11 2100442500 Plug 30 DP-1187 2734 BI HEYCO X
-- 8208820003 CEPH arm assy X
