SERVICE MANUAL
Technical features
(Rev. 0) RTG PLUS (120V)
4-3
X-ray tube features
Manufacturer CEI – Bologna Italy
Type CEI OPX/105
Focus 0.5 IEC 336
Inherent filtration 0.5 mm Al eq.
Anode tilt 5°
Anode material Tungsten
Nominal voltage 105 kVp
Filament maximum current 4A
Filament maximum voltage 8V
Anode thermal capacity 30 kJ
Weight of apparatus and parts
Slider net weight 123.5 pounds (56 kg)
Column net weight 106 pounds (48 kg)
Tubehead net weight 53 pounds (24 kg)
CEPH device net weight 35 pounds (16 kg)
Control unit net weight 62 pounds (28 kg)
Slider counterweights net weight 203 pounds (92 kg)
Environmental conditions
Maximum operating temperature range
+50°F ÷ +104°F (+10° ÷ +40°)
Operating relative humidity range
30% ÷ 75%
Transportation and storage temperature
range
-4°F ÷ +158°F (-20° ÷ +70°)
Maximum transportation and storage
relative humidity
< 90% non condensing
Minimum atmospheric pressure for
transportation and storage
630 hPa
