SERVICE MANUAL
Installation
(Rev. 0) RTG PLUS (120V)
6-9
6. Drill wall and floor at the marks made previously.
Figure 6-12
NOTE:
To fasten the wall bracket to masonrywe recommend expanding metal
dowels with a screw diam. 8mm while for the base plate it will be
sufficient dowels with screw diam.6mm. Where a wooden support is
utilized, we recommend a la bolt of 3/8" diameter.
*
