SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-34
TMJ2
TMJ2TMJ2
TMJ2
To switch from TMJ1 to TMJ2 data control, use the "R" button, select the
TMJ2 function and bring the cassette tray from the Pan/TMJ1 position
to the TMJ2 position by turning the reeded handle 13 (see Figure 7-12)
counterclockwise.
1. Press "T" (31) and release it immediately to display "T 020" (heating
time, cannot be changed) corresponding to 2 seconds.
2. Press "s" (39) to display the string "A1 ......." (X-ray emission start
angle, 2nd exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final Test Table” (see the last
page of the User’s Manual).
3. Press "s" (39) to display the string "A2 ......." (X-ray emission end
angle, 2nd exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final test Table”.
4. Press "s" (39) to display the string "A3 ......." (modifiable but
insignificant).
5. Press "s" (39) to display the string "A4 ......." (modifiable but
insignificant).
6. Press "s" (39) to display the string "A5 ......." (X-ray emission start
angle, 3rd exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final Test Table”.
7. Press "s" (39) to display the string "A6 ......." (X-ray emission end
angle, 3rd exposure). This setting can be modified of max ±2° with
respect to the value indicated in the “Final test Table”.
