Original User Guide | Pedelec Impulse Evo / Impulse Evo Next Version 4 EN-29
3.10.1.4 Shift unit: Shifter adjustment
Path: Settings | Device settings | Shift unit | Shifter adjustment
The electronic shifter works with a gear cable. This cable can easily stretch
over its life, or needs to be readjusted after being renewed. You can
performneadjustmentofthetensionin“Shifteradjustment”.
1. Navigate to the “Settings” menu as described in  6.4.1 Configuring
settings in the main menu Page EN-54.
2. You can choose between:
-2.50 mm -2.00 mm -1.50 mm -1.00 mm -0.50 mm 0.00 mm 0.50 mm 1.00 mm 1.50 mm 2.00 mm 2.50 mm
3. Select the required option using the
/
buttons. The selection is
highlighted.
4. Conrmyourselectionbybrieypressingthe
button. You return to
sub-level 3.
IMPORTANT
The shifter is adjusted correctly when the
two yellow marker lines line up exactly.
Whetherthisisso,youcanxinthe
adjustment gear (mostly the 4th gear). If
the adjustment range is too short, i.e. it
is not possible to line up the two yellow
marker lines, the position of the gear hub
sliding block must be moved.
Marker line
2. Youcanselectbetweendierentstartgearsandsetting“O”(nostart
gear):
1 2 3 4 5 6 7 O
1st gear 2nd gear 3rd gear 4th gear 5th gear 6th gear 7thgear No gear
*The number of gears displayed depends on the gear shifter you have.
3. Select the required option using the
/
buttons. The selection is
highlighted.
4. Conrmyourselectionbybrieypressingthe
button.
You return to column "Top Gear at".
Top Gear at
Here you can select the speed at which the shift (in the automatic mode)
should shift to the highest gear.
20 km/h 22 km/h 24 km/h 26 km/h 28 km/h 30 km/h 32 km/h
5. Select the required option using the
/
buttons. The selection is
highlighted.
6. Conrmyourselectionbybrieypressingthe
button. You return to
sub level 3.
For sporty riders, who feel comfortable with higher cadence,
we recommend the adjustment range 28 to 32 km/h.
Cyclists who prefer lower tread frequencies feel the most
comfortable at speeds of 20 to 26 km/h
