GAVIN-6C Instruction Manual
- 9 -
 Power Switch
Push the switch upward to turn on the transmitter, push downward to turn off.
 Neck Strap Attachment
For a long flight you can choose to use a neck strap for easy handing. The
neck strap attachment is on the neutral position, in order to get the best
balance for transmitter.
 Switch
 HOLD: 2 positions, alternate, short lever
 FMOD: 3 positions, alternate, short lever
 GEAR: 2 positions, alternate, short lever
 FLAP: 2 positions, alternate, short lever
 TRAINER: 2 positions, momentary, long lever
Generally, the throttle hold switch is set to HOLD, acrobatic flight switch is set
to FMOD, landing gear switch is set to GEAR, flap switch is set to FLAP.
Users can choose the above switches for specified functions according to
individual habits. For details, please see Function Set [Func Set] (Page 40).
 Sticks
When the Stick Mode is set to MODE 1, the positions of sticks are shown in
the figure.
 Digital Trims
This transmitter is equipped with four digital trims. Each time you press a trim
button, the trim position moves one step. You can always monitor trim
positions by referencing the LCD screen.
CAUTION: The trim positions you have set will be stored in memory and will
remain there even the transmitter powered off.
 Keys
 EXT: exit key, press this key to return to the previous menu.
 UP: press this key to select the menu upward.
 DOWN: press this key to select the menu downward.
