GAVIN-6C Instruction Manual
- 20 -
Rev Set
1/6
1. CH1 ：
2.CH2：
3.CH3：
Norm
Norm
Norm
2. Press UP or DOWN key to select the channel, and then press R/+ or L/- key
to set the value of the channel.
Values:
 Norm: It means the servo direction of selected channel is the normal
direction.
 Rev: It means the servo direction of selected channel is the reverse
direction.
The default is Norm.
WARNING:
 Please set the Rev Set function before setting the Fail Safe function.
Otherwise it will affect the servo direction of the fail safe (opposite to the
original direction).
 Generally, do not set the value of CH3 (throttle channel) to Rev.
End Point [End Point]
The adjustment is carried out with reference to the neutral position. This function
allows independent adjustment of the servo maximum movement in either
direction, for each channel.
When multiple channel mixing is used, the resultant servo movement angle may
become too large, and an unreasonable force be applied to the linkages. It is
possible to limit the maximum movement of the servos by setting the end point.
Setting Method:
1. In the Model Parameter menu, press UP or DOWN key to select End Point,
and then press ENT key to enter the setting interface.
