GAVIN-6C Instruction Manual
- 14 -
4. Use a Phillips screwdriver to adjust the spring strength as you prefer by
turning the screw of the stick you want to adjust. Turning the screw clockwise
increases the tension, counter clockwise to loosen.
CAUTION: Do not loosen the screw too much, the stick may not operate.
5. Connect the wirings between the PCB and rear cover, close the rear cover,
and then tighten the six screws on the rear cover.
6. Install the batteries and the battery cover.
Change the Location of Throttle Stick
If you want to change the throttle stick from right-hand to left-hand, or change
from left-hand to right-hand, it is need to change the location of the throttle stick,
and then change the stick mode. The following is the method for changing the
location of the throttle stick.
Tools: Phillips screwdriver, ESD wrist strap or ESD gloves.
Conditions: Before operating, please wear an ESD wrist strap or ESD gloves.
Steps:
1. Open the battery cover, and remove the batteries.
2. Remove the six screws on the rear cover with a Phillips screwdriver.
3. Open the rear cover and remove the wirings between the PCB and rear
cover.
The wirings: a connection between the battery pack and the interface marked
with J1 on PCB, a connection between TRAINER switch and the interface
marked with TRAINER on PCB, a connection between USB interface and the
interface marked with USB on PCB.
CAUTION: Please gently ease off the transmitter's rear cover, to avoid
breaking the wirings.
4. Remove the eight screws fixed the sticks on the front cover with a Phillips
screwdriver.
