DETRUM GAVIN-6C - Timer Set [Timer 1;2;3 Set]

GAVIN-6C Instruction Manual
- 45 -
AILERON
1/1
1.Set ：
Fail Safe
2.
0
4. Set the value to desired position.
Values for each channel: -120~120. The default values for each channel are 0,
0, -100, 0, 0, and 0.
Timer Set [Timer 1/2/3 Set]
This transmitter incorporates two timer systems which are displayed on the main
screen. Take the timer 1 setting method as an example.
Setting Method:
1. In the Model Set menu, press UP or DOWN key to select Timer 1 Set, and
then press ENT key to enter the setting interface.
Timer 1 Set
1/5
1.Type：
2.Control SW：
3.THR Position：
OFF
THR
-90
2. Press UP or DOWN key to select Type, and then press R/+ or L/- key to set
the timer type.
Values:
 OFF: This timer is disabled. You do not need to set the following items
when OFF is selected.
 Hidden: This timer is enabled, but does not display on the main screen.
 UP Timer: This timer is enabled, and displays on the main screen as up
