GAVIN-6C Instruction Manual
- 31 -
default is -100.
ELE▶RUD: This parameter is used to set the mixing rate (percentage) from
elevator channel to rudder channel. Values: -100~100. If the value is negative,
it will adjust the rudder operation in the negative direction. If the value is
positive, it will adjust the rudder operation in the positive direction. The default
is 100.
RUD▶RUD: This parameter is used to set the mixing rate (percentage) from
rudder channel to itself. Values: -100~100. If the value is negative, it will
adjust the rudder operation in the negative direction. If the value is positive, it
will adjust the rudder operation in the positive direction. The default is 100.
CAUTION: You can not set V-tail mixing when Delta mixing has already
been set. In order to enable V-tail mixing, you need to cancel Delta mixing
function first (modify the value of Mix SW to OFF). However, it is allowed to
use V-tail and Flaperon mixing simultaneously.
Flaperon Mixing [Flaperon Mix]
Corresponding model type: airplane, 2 ailerons
The two aileron servos are connected to channel 1 (AILE) and channel 6 (AUX1).
Flaperon mixing allows the ailerons to operate in the same direction (as ailerons)
and in opposing directions (as flaps).
Setting Method:
