V-tail mixing mixes channel 2 (elevator) to channel 4 (rudder) allowing the
ruddervaotrs to operate both as rudders and elevators.
Setting Method:
1. In the Mix Set setting interface, press UP or DOWN key to select V-tail Mix,
and then press ENT key to enter the setting interface.
V-tail Mix
1/1
1.Mix SW ：
OFF
2. Modify the value of Mix SW to ON by pressing R/+ key, to activate V-tail
mixing function.
The setting interface is shown in the following figure.
1/5
1. Mix SW：
ON
2.ELE
3.RUD
100
-100
ELE：
ELE：
V-tail Mix
3. Press UP or DOWN key to select the setting item, and then press R/+ or L/-
key to set the value of the item.
 ELE▶ELE: This parameter is used to set the mixing rate (percentage) from
elevator channel to itself. Values: -100~100. If the value is negative, it will
adjust the elevator operation in the negative direction. If the value is positive,
it will adjust the elevator operation in the positive direction. The default is 100.
 RUD▶ELE: This parameter is used to set the mixing rate (percentage) from
rudder channel to elevator channel. Values: -100~100. If the value is negative,
it will adjust the elevator operation in the negative direction. If the value is
positive, it will adjust the elevator operation in the positive direction. The
