GAVIN-6C Instruction Manual
- 11 -
 Note:
 When the Stick Mode is set to MODE 1, the positions of trims are shown in
the figure. The positions are different depending on the stick mode. For
details, please refer to Stick Mode [Stick Mode] (Page 49).
 For details about the flight modes, please refer to Flight Mode (Page 17).
Receiver
Specifications
Parameters
DETRUM RXC7 Specifications
Type
2.4GHz 7-channel
Sensitivity
-95dBm
Frequency interval
larger than or equal to 4MHz
Power supply
4.8~6V
Weight
10g
Size
39mm * 28.5mm * 14.5mm
Features
 Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple
frequency-hopping technology, the receiver has high sensitivity and strong
anti-interference performance.
 Using diversity antenna, ensure that the receive signals are stable.
 Multiple channels output the signals simultaneously, to enhance the
synchronized movement.
 The receiver has a memory function for frequency and ID.
 The receiver has the fail safe function.
 The distance for signal control is more than 1000 meters.
Receiver Connections
The channels of DETRUM RXC7 receiver are labeled with names, as shown in
the following figure.
