3.2.2. Channel Setup IOLITE® 
In the channel setup you can see a preview of the connected devices on the left side. 

When you click on a connector in the image the corresponding channel in the Channel setup                
grid will automatically be selected. This also works the other way around: when you select a                
channel (or multiple channels) in the setup grid, the corresponding connectors in the image              
will be highlighted. 

The sampling rate will be set for all connected IOLITE® slices: of course only up to the max. sampling                   
rate of the individual slices. 

Channel setup IOLITEr 

Channel setup IOLITEs 
 
