IOLITE® 
TECHNICAL REFERENCE MANUAL
5.1.5. DIO: Connectors
IOLITE-32xDI and IOLITE-32xDO modules have 9-pin terminal block connectors with 2.50 mm pitch for
digital input / output. 8 pins on a 9-pin connector bank are used for digital inputs and pin 9 for common
GND.
Additionally, there is a 2-pin terminal block connector with a 2.50 mm pitch for PWR OUT function. 
IOLITE-32xDI f ront
IOLITE-32xDO f ront
IOLITE-8xDI-4xDO front
IOLITE® V20-1 53 / 101
