IOLITE® 

TECHNICAL REFERENCE MANUAL 



4.2. System speciﬁcations 



System 

IOLITEr 

IOLITEs 

Number of slots 

12 

8 

Synchronization 

2x SIRIUS® SYNC on L00B4f 

Sync Accuracy 

below 1 sample to Sirius® 

Dual EtherCAT® interface 

Number of buses 

Two (both with buffered DAQ or real time) 

Data Rate 

Dual 100 Mbit bus speed 

Max. Throughput per Chain 

From 6 MB/s to 10 MB/s 

Bus 1 connectors 

2x Ethernet RJ45 

2x LEMO 1T 

Bus 2 connectors 

2x Ethernet RJ45 

Minimum delay 

(analog input to EtherCAT® bus) 

70 µs 

Minimum EtherCAT® cycle time 

100 µs 

Power 

Power supply 

Dual redundant 12 - 48 V DC 

Power consumption 

9 W to 11 W (incl. IOLITE-GATE) 

IOLITE-GATE: Max. 1.9 W 

8 W (Max: 9 W) 

Environmental 

Operating Temperature 

-10 to 50 °C 

Storage Temperature 

-40 to 85 °C 

Humidity 

5 to 95 % RH non-condensing at 50 °C 

IP rating 

IP30 

IP40 

Physical 

Dimensions 

483 x 148 x 133 mm 

266 x 169 x 139 mm 

Weight 

3.1 kg (incl. IOLITE-GATE) 

230 g (IOLITE-GATE) 

2.6 kg 



 

IOLITE® V20-1 26 / 101  
